Performance Parameters

• Light Sources: Aiming: 625nm LED; Illumination: 4000K LED
• Supported Symbologies:
  1D: UPC/EAN/JAN, UPC-A, UPC-E, EAN-8, EAN-13, JAN-8, JAN-13, ISBN/ISSN, Code 39 (Full ASCII), Codabar (NW7), Code 128, EAN 128, Code 93, Interleaved 2 of 5 (ITF), Addendum 2 of 5, IATA Code, MSI/Plessy, China Postal Code, Code 32 (Italian Pharmacode), RSS-14, RSS-Limited and RSS-Expanded.
  2D: QR Code, Data Matrix, PDF417, Aztec, MaxiCode, DotCode and GS1 DataBar Stacked.
  OCR: Chinese ID cards and selected international identification documents.
• Image Sensor: CMOS
• Image Resolution: 1280 × 800 pixels
• Scan Speed: 60 fps
• Scan Mode: Handheld (Manual) / Hands-free (Automatic)
• Scan Accuracy: ≥ 4mil @ Code 39
• Print Contrast: ≥ 20%
• Depth of Scan Field: 25–300mm @ EAN 13mil, PCS 100%; 30–350mm @ QR 20mil, PCS 100%
• Scan Angle: Left and right: ±55°; Front and rear: ±55°; Rotation: 360°
• Field of View: 41° horizontal; 28° vertical
• Transmission Mode: Wired transmission
• Visual Indicator: Red and blue LED lights and buzzer
• Interface: USB keyboard, USB virtual serial port and RS-232
• Compatible Systems: Windows, iOS and Android

Physical Parameters

• Dimensions: 174 × 66 × 94mm
• Weight: 205g, including cable
• Material: ABS+PC and TPU
• Cable Length: 1.8m straight cable
• Shock Resistance: Withstands drops of up to 2 meters
• Ingress Protection: IP52

Environmental Parameters

• Operating Temperature: -20°C to +60°C
• Storage Temperature: -40°C to +70°C
• Relative Humidity: 5% to 95% RH, non-condensing
• Electrostatic Protection: ±8kV, direct discharge
• Ambient Brightness: 0 to 100,000 lux

Electronic Parameters

• Working Voltage: 5VDC ±5%
• Operating Current: 190mA, typical value
• Standby Current: 70mA
