Performance Parameters

• CPU: 32-bit ARM
• Operating System: Windows / iOS / Android
• Light Source: White LED
• Supported Symbologies:
  1D: Code 128, EAN-13, EAN-8, Code 39, UPC-A, UPC-E, Codabar, Interleaved 2 of 5, ITF-6, ITF-14, ISBN, Code 93, UCC/EAN-128, GS1 DataBar, Matrix 2 of 5, Code 11, Industrial 2 of 5, Standard 2 of 5, Plessey and MSI-Plessey.
  2D: QR Code, Micro QR, PDF417, MicroPDF, Data Matrix, Aztec, MaxiCode and Han Xin.
  OCR: ID cards and passports.
• Image Sensor: CMOS
• Image Resolution: 1280 × 800 pixels
• Scan Speed: 60 fps
• Scan Mode: Handheld (Manual) / Hands-free (Automatic)
• Scan Accuracy: ≥ 4mil @ Code 39
• Print Contrast: ≥ 30%
• Scan Angle: Pitch: ±55°; Skew: ±50°; Rotation: 360°
• Field of View: 52° horizontal; 39° vertical
• Motion Tolerance: 2.0m/s
• Scan Indicator: Buzzer and vibration motor
• Interface: USB HID and USB CDC; TTL232 and RS-232 optional

Depth of Scan Field

• 13mil EAN-13: 30–390mm
• 5mil Code 39 (10 bytes): 40–180mm
• 15mil QR Code: 20–280mm
• 6.67mil PDF417: 40–190mm
• 20mil Data Matrix: 40–130mm
• 32mil QR Code (WeChat): 40–1,000mm

NFC Parameters

• Reading Distance: 0–60mm
• Reading Frequency: 13.56MHz
• Supported Types: S50, S70, NTAG 213, NTAG 215, MIFARE Ultralight, Fudan M1, MIFARE DESFire EV1, EV2 and EV3, MIFARE Plus 2K, MIFARE Plus 4K and SR176

Physical Parameters

• Dimensions: 32.6 × 84 × 87mm (H × W × L)
• Weight: 80g, without cable
• Material: ABS
• Shock Resistance: Designed to withstand drops of up to 2 meters
• Ingress Protection: IP42
• Accessories: USB cable; optional TTL232 and RS-232 cables

Environmental Parameters

• Operating Temperature: -20°C to +50°C
• Storage Temperature: -40°C to +70°C
• Relative Humidity: 5% to 95% RH, non-condensing
• Ambient Brightness: 0 to 100,000 lux (daylight)

Electronic Parameters

• Input Voltage: DC 5V to 24V
• Operating Current: Maximum 640mA @ 5V; typical 380mA @ 5V
• Typical Power Consumption: 1.9W
