Performance Characteristics

CPU: ARM Cortex-A53, Octa-core 2.0GHz / 2.3GHz
Operating System: Android 11.0 / 13.0
Memory: 4GB RAM + 64GB ROM / 3GB RAM + 32GB ROM (optional)
SIM Card Slots: 2 × Nano SIM cards
Storage Expansion: 1 × Micro SD Card (SDHC / SDXC supported, up to 512GB)

Physical Characteristics

Display: 5.5” HD+ IPS 720×1440, industrial-grade capacitive multi-touch
Battery: Removable Lithium Battery, 3.85V / 5000mAh
Backup Battery: Supports hot-swap (device keeps working, optional)
Dimensions: 157.8 × 75.5 × 14.9 mm (L×W×H)
Weight: 250g (with battery)
Ports: 1 × USB Type-C (supports USB 2.0, OTG, fast charging)
Expansion Ports:
• 2-pin Rear POGO PIN – Trigger key
• 2-pin Bottom POGO PIN – Charging port
Keys: Power key ×1, Volume (+/–) keys ×1, Function key ×1, Scan keys ×2
Prompts: Vibration, Multi-color LEDs, Audio
Audio: Speaker, Receiver, Dual Microphones (noise reduction)

Sensors

G-Sensor, Light Sensor, Proximity Sensor
Optional: E-compass, Gyroscope

Data Capture

Scan Engine: Newland CM60
Rear Camera: 13 Megapixels, flash support, auto focus
Front Camera: 5 Megapixels, fixed focus
NFC: Supports ISO15693 / ISO14443A/B / Mifare / Felica cards

Network Connection

Wireless WAN
Eurasian:
4G – B34/B38/B39/B40/B41/B1/B3/B5/B7/B8/B20/B28A/B28B
3G – B1/B5/B8/B34/B39
2G – 850/900/1800/1900

American:
4G – B38/B41/B1/B2/B3/B4/B5/B7/B12/B17/B19/B26/B28A/B28B/B66
3G – B1/B2/B4/B5/B8
2G – 850/900/1800/1900

Wireless LAN
2.4GHz & 5GHz dual-band Wi-Fi, supports 802.11r fast roaming
IEEE 802.11 a/b/g/n/ac/ax ready (d/e/h/i/j/k/r/v/w)

Wireless PAN
Bluetooth 5.0 + BR/EDR + BLE

GPS
GPS L1, GLONASS, Beidou, Galileo

User Environment

Operating Temperature: -20°C ~ +60°C
Storage Temperature: -40°C ~ +70°C
Charging Temperature: 0°C ~ +45°C
Humidity: 5%–95% RH (non-condensing)
Sealing Standard: IP68
Drop Spec: 1.5m
Tumble Spec: 1000 drops (500 cycles) at 0.5m, room temperature
ESD: ±15 kV Air Discharge / ±8 kV Direct Discharge

Accessories

Standard: Power Adapter ×1, USB Cable ×1, Battery ×1
Optional: Lanyard, Hand Strap, Cradle, Pistol Grip, Protective Case, Screen Protector
